CAT. No. AC1773

HDMI to Composite AV Converter with Power Supply
product image thumb
product image thumb
product image thumb

HDMI to Composite AV Converter with Power Supply

$49.95
Convert digital HDMI sources to analogue composite video and stereo audio devices that have the older style RCA ports. Mains adapter included.
Available

Description

1 Year Warranty

Convert your digital HDMI signal to a standard composite audio / video signal. This is very handy for adapting a DVD player or gaming console to an older TV, since many of these new devices no longer offer analogue outputs. Supports PAL and NTSC standards. USB cable and power supply included to provide power to the unit.

Features:

- Quality Conversion
- Plug & Play
- Digital to Analogue
- Input Video Signal: HDMI
- Output Video Signal: Composite RCA
- HDMI Input Resolution:
640 x 480 @ 60Hz
800 x 600 @ 60Hz
1024 x 768 @ 60Hz
 1280 x 720 @ 60Hz
1280 x 1024 @ 60Hz
1360 x 768 @ 60Hz
1600 x 1200 @ 60Hz
1920 x 1080 @ 60Hz
480i/p @ 60Hz
576i/p @ 60Hz
720p @ 50/60Hz
1080i/p @ 50/60Hz
- Supported TV Standard: PAL/NTSC M.(NTSC-J)
- Power Consumption: 5W

    Specifications

    Product Dimensions

    Height
    		 21mm
    Width
    		 67mm
    Depth
    		 57mm
    Weight
    		 42g

    Packaged Dimensions

    Packaged Length
    		 11.2cm
    Packaged Width
    		 9.2cm
    Packaged Weight
    		 0.228kg
    Packaged Volume
    		 0.66976l
    Packaged Height
    		 6.5cm

    A/V Switcher or Converter

    Input type
    		 HDMI
    Switcher/Converter Type
    		 Converter
    Input Connection
    		 HDMI Type-A
    Output Type
    		 Composite Video and Audio
    Output Connection
    		 3 RCA Connection
    Power Requirement
    		 External Power Required
    Number of inputs
    		 1pc
    Number of Outputs
    		 1pc

    Power from Plugpack

    DC Plugpack Voltage
    		 5V
    Suitable PSU Included

    Video Resolution

    Maximum Vertical Resolution
    		 1080Pixel
    Maximum Horizontal Resolution
    		 1920Pixel
    Supported Display Resolution
    		 1080p (1920 x 1080)

    Product Availability

    Availability
    		 Stocked item
    Warranty: 12 Months

    Downloads

      Articles
      Articles

    AC1773-manualMain.pdf
