TERMINAL BARRIER PCB, TRANSPARENT COVER 4WAY
TERMINAL BARRIER PCB, TRANSPARENT COVER 4WAY

CAT. No. HM3162

TERMINAL BARRIER PCB, TRANSPARENT COVER 4WAY
product image thumb

TERMINAL BARRIER PCB, TRANSPARENT COVER 4WAY

$6.95
Pitch: 9.5mmBarrier Material: Thermoplastic (UL94V-0), BlackTerminals: Tint Plated Brass (Standard)Screws: Nickel Plated SteelWire Range AWG: 12-22 S...
Available

Description

Barrier Material: Thermoplastic (UL=94V-0), Black
Terminals: Tint Plated Brass (Standard)
Screws: Nickel Plated Steel
Wire Range AWG: 12-22 STR
Cover Material: PC
Insulation withstands voltage AC 2000V/Min
Pole HD-12-? P HD-12-? PH
A (Px9.5)+1.4 (P+2)*9.5+1.4
B (P-1)*9.5 (P+1)*9.5

    Specifications

    Terminal Strip

    Terminal Spacing
    		 9.5mm
    Type
    		 Screw Terminal
    Device
    		 Terminal
    Insulation Dielectric Voltage Rating
    		 2V
    Number of Contacts
    		 4pc
    Attachment Method
    		 PCB
    Insulation Resistance
    		 500M?

    DC Current Rating

    DC current rating
    		 25A

    AC Voltage Rating

    AC Voltage rating
    		 300V

    AC Current Rating

    AC current rating
    		 25A

    Product Mounting

    Attachment / Securing Method
    		 Screw Down
    Mounting Method
    		 PCB

    Packaged Dimensions

    Packaged Length
    		 6cm
    Packaged Width
    		 1.8cm
    Packaged Weight
    		 0.015kg
    Packaged Volume
    		 0.0162l
    Packaged Height
    		 1.5cm

    Product Availability

    Availability
    		 Stocked item
