CAT. No. PT4438

175A Anderson Waterproof Boot Load Side
product image thumb
product image thumb

175A Anderson Waterproof Boot Load Side

$29.95
175A Anderson waterproof boot load side
Available

Description

1 Year Warranty

These soft shell boots provide water, dirt, chemical and UV protection for the high current Anderson connectors. The durable boots shield the connectors from water and dirt to IP64 when connected or by itself when the integral cover is used. The terminals of the rubber boot can also be customised to fit cables in-between 12-6 AWG (4-16mm²) wires.

Features:

•    IP64 protection
•    Resistant to UV, Roadway Chemical and Ozone
•    Splash resistant when connected and by itself when the integral cover is used
•    Customise boot terminals to fit your cables from 12-6 AWG which is 4-16mm²




    Specifications

    Product Dimensions


    Length
    107mm, 107mm
    Height
    140mm, 140mm
    Width
    42mm, 42mm

    Packaged Dimensions


    Packaged Length
    14cm
    Packaged Width
    10.5cm
    Packaged Weight
    0.14kg
    Packaged Volume
    0.6174l
    Packaged Height
    4.2cm

    Additional Dimensions


    Length
    107mm, 107mm
    Height
    140mm, 140mm
    Dimensions details
    dimensions when connected
    Width
    42mm, 42mm

    Plug or Socket


    Case Material
    Rubber

    Environmental Protection


    UV resistance
    Dust resistance

    Product Availability


    Availability
    Stocked item
    Warranty: 12 Months
