IP67 True RMS Autoranging Cat IV DMM
IP67 True RMS Autoranging Cat IV DMM
IP67 True RMS Autoranging Cat IV DMM
IP67 True RMS Autoranging Cat IV DMM
IP67 True RMS Autoranging Cat IV DMM

CAT. No. QM1549

IP67 True RMS Autoranging Cat IV DMM
product image thumb
product image thumb
product image thumb
product image thumb

IP67 True RMS Autoranging Cat IV DMM

$119
An excellent true RMS multimeter that features a large, easily read display and carries an IP67 environmental rating • IP67 waterproof • True RMS • Auto power-off • Backlight • Data hold and relative function
Available

Description

Batteries Included

This is an excellent true RMS multimeter that features a large, easily read display and carries an IP67 environmental rating. This means the multimeter is waterproof and will not be damaged if accidentally dropped into water or left out in the rain. The meter has data should and relative measurement capabilities and is housed in a robust, double moulded case. Includes leads, soft carry case and user manual.

Features:

• IP67 waterproof
• True RMS
• Auto power-off
• Backlight
• Data hold & relative function
• Diode test
• Autoranging
• Audible continuity
• 10A current range
• Double moulded case
• Display 4000 count
• Security Class Cat IV 600V
• Basic DCV accuracy 0.500%
• Ave/RMS True RMS
• Input impedance 10M
• Special features IP67, data-hold, relative measurement, backlight

For More info on Digital Multimeters.

    Specifications

    Measures Current DC

    DC Current Accuracy
    		 1.20000000%
    DC Current Ranges
    		 4mA, 40mA, 400mA, 10A

    Measures Current AC

    AC Current Accuracy
    		 1.80000000%
    AC Current Ranges
    		 4mA, 40mA, 400mA, 10A

    Measures Voltage AC

    AC Voltage Ranges
    		 400mV, 4V, 40V, 400V, 1000V
    AC Voltage Accuracy
    		 0.80000000%

    Measures Voltage DC

    DC Voltage Accuracy
    		 0.50000000%
    DC Voltage Ranges
    		 400mV, 4V, 40V, 400V, 1000V

    Measures Resistance

    Resistance Ranges
    		 400?, 4k?, 40k?, 400k?, 40M?
    Resistance Accuracy
    		 0.80000000%

    Meter Safety Rating

    Safety Rating Max Volt
    		 600V
    Safety Rating Cat
    		 Cat IV

    Measures Capacitance

    Capacitance Accuracy
    		 3%
    Capacitance Ranges
    		 4nF, 40nF, 4µF, 40µF, 100µF

    Measures Frequency

    Frequency Ranges
    		 4kHz, 40kHz, 400kHz, 4MHz, 10MHz
    Frequency Accuracy
    		 1.50000000%

    Ingress Protection Rating

    IP Rating certificate
    Dust/Particle Ingress Protection
    		 6 - Dust tight, no ingress of dust
    Liquid/Moisture Ingress Protection
    		 7 - Immersion up to 1m

    Digital Multi-Meter

    Autorange
    Count Maximum Reading
    		 4000 count
    True RMS
    Measures duty cycle

    Meter Data Control

    Data Hold
    Relative Measure

    Measures Continuity

    Continuity indicator
    		 Needle

    Meter Probes

    Probe rating voltage
    		 600V
    Probe safety rating
    		 Cat IV

    Meter

    Input Protection Fuse
    		 500mA, 10mA
    Carry Case Included
    Casing
    		 Plastic
    Measures diode
    Meter Input Impedence
    		 10?

    Power from disposable battery

    Batteries can be replaced by user
    Battery quantity
    		 1pc
    Batteries included
    How is battery compartment kept closed
    		 Clip and Screw
    Size / Shape
    		 9V
    Compartment location
    		 Internal / In-built

    Product Dimensions

    Length
    		 182mm
    Width
    		 82mm
    Depth
    		 55mm

    Packaged Dimensions

    Packaged Length
    		 23.3cm
    Packaged Width
    		 13.2cm
    Packaged Weight
    		 0.664kg
    Packaged Volume
    		 2.46048l
    Packaged Height
    		 8cm

    Meter Display

    Display Backlight
    Display Type
    		 LCD

    Product Availability

    Availability
    		 Stocked item
    Warranty: 9999 Months
    Special terms or exclusions: Lifetime Warranty
