Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2

CAT. No. QV5050

Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2
product image thumb
product image thumb
product image thumb
product image thumb
product image thumb
product image thumb
product image thumb
product image thumb

Concord 4 Channel HD DVR Package - 4x1080p PIR Bullet Cameras v2

$449
- 1TB HDD - 4 Weatherproof 1080p Bullet Cameras included - PIR Motion Detection - Smartphone Viewing with Notifications

Out of Stock

Description

2 Year Warranty
Digital Video Recorder
4 Channel
1080p HD Bullet Camera
1TB Internal Storage
1080p HD
Get it on Google Play
Download on the App Store

The kit includes four weatherproof HD cameras to capture vision in high definition features built-in infrared LEDs for night vision up to 20m and Thermal Detect Technology to help prevent false triggers.


The DVR includes a built-in 1TB HDD and supports cloud storage such as Dropbox™ or Google Drive to safeguard your data, and push notifications to send alerts to your phone.

Watch live or playback video on your HDTV or LCD monitor via HDMI or VGA or log in remotely via your Apple or Android compatible Smartphone or Tablet using the free app. Connecting your Smartphone is made easy using Peer-to-Peer (P2P) technology and scanning a QR code with the app.

There is also support for two IP camera* (not included), making the system 6 channel in total. A USB mouse is included to navigate the on-screen menus, and there is a second USB 2.0 port that allows you to save recordings to a USB thumb drive for sharing or viewing on other devices, as well as uploading firmware updates.

Features:
• High Definition Surveillance System
• 4 Weatherproof 1080p Bullet Cameras
• 1TB Internal Storage
• PIR Motion Detection
• Smartphone Viewing & Notification
• Requires an external switch or router


    Specifications

    Digital/Network Video Recorder

    Camera Connection
    		 BNC
    Total Recording Channels
    		 5ch
    Audio Connection
    		 RCA
    Remote Access
    		 Android(R) App, iPhone(R) App
    Audio Outputs
    		 1ch
    Notification Functions
    		 Push notice to app
    Video Channels (IP Connection)
    		 1ch
    Audio Inputs
    		 1ch
    Video Output (Auxilliary/Fixed Display)
    		 HDMI Type-A
    Video Channels (Direct Connection)
    		 4ch
    Recording Schedule Functions
    		 Continuous Record, Motion Activation
    Video Output (Monitor)
    		 HDMI Type-A, D15 HD (VGA)

    Surveillance Equipment

    Equipment Type
    		 Surveillance Package (DVR/NVR + Camera)

    Power from Plugpack

    DC Plugpack Voltage
    		 12V, 12V
    PSU Powers
    		 Main Product, Camera

    Power from Plugpack (secondary)

    DC Plugpack Voltage
    		 12V, 12V
    Suitable PSU Included
    PSU Powers
    		 Main Product, Camera

    Digital Storage Details

    Expandable
    Maximum Capacity
    		 6TB
    Included Capacity
    		 1TB

    USB Connectivity

    Port Details
    		 2 USB ports for keyboard and mouse
    USB Port Types
    		 USB Type A
    Number of USB ports
    		 2 ports

    Video Resolution

    Supported Display Resolution
    		 4MP (2592 x 1520)

    Smartphone App Details

    Apps to suit
    		 Apple iOS, Android

    CCTV Cameras

    Thermal Detection PIR Sensor
    Infrared Enabled
    Infrared Range
    		 20m
    Output Signal
    		 TVI
    Type of Camera
    		 Bullet
    Video Output Connection
    		 BNC
    Lens Angle
    		 82°
    Resolution
    		 1080p (1920 x 1080)

    Ingress Protection Rating

    IP Rating
    		 IP67
    Dust/Particle Ingress Protection
    		 6 - Dust tight, no ingress of dust
    Liquid/Moisture Ingress Protection
    		 7 - Immersion up to 1m
    IP rating for
    		 Camera

    Box Contents

    •
    		 1 x 4 Channel DVR, 4 x HD PIR Bullet Cameras, 4 x 18m Cables, 1 x Network Cable, 1 × USB Mouse, 1 x DVR Power Adaptor, 1 x Camera Power Adaptor, 1 x HDMI Cable

    Additional Dimensions

    Length
    		 180mm
    Dimensions details
    		 Camera Dimensions
    Width
    		 70mm, 200mm
    Depth
    		 68mm, 200mm

    Product Dimensions

    Height
    		 45mm
    Width
    		 70mm, 200mm
    Dimension details
    		 DVR Dimensions
    Depth
    		 68mm, 200mm

    Product Availability

    Availability
    		 Stocked item

    Packaged Dimensions

    Packaged Length
    		 44.7cm
    Packaged Width
    		 29.8cm
    Packaged Weight
    		 5.334kg
    Packaged Volume
    		 26.6412l
    Packaged Height
    		 20cm
    Warranty: 24 Months

    Downloads

    QV5050-manualMain.pdf
    QV5050-firmwareMain.zip
