CAT. No. QV5056

Concord 16 Channel HD DVR Package - 8x1080p PIR Cameras
product image thumb
product image thumb
product image thumb
product image thumb
product image thumb
product image thumb
product image thumb

Concord 16 Channel HD DVR Package - 8x1080p PIR Cameras

$999
- 2TB HDD - 8 Weatherproof 1080p Bullet Cameras included - PIR Motion Detection - Smartphone Viewing with Notifications

Out of Stock

Description

2 Year Warranty
Digital Video Recorder
1080p HD
2TB Internal Storage
1080p HD Bullet Camera

Protect your property with this easy to install surveillance system. The kit includes four weatherproof HD cameras to capture vision in high definition features built-in infrared LEDs for night vision up to 15m and Thermal Detect Technology to help prevent false triggers.

The DVR includes a built-in 2TB HDD and supports FTP storage or Dropbox™ Cloud Storage to safeguard your data and push notifications to send alerts to your phone.

Watch live or playback video on your HDTV or LCD monitor via HDMI or VGA or log in remotely via your Apple or Anroid compatible Smartphone or Tablet using the free app.

Connecting your Smartphone is made easy using Peer-to-Peer (P2P) technology and scanning a QR code with the app.

A USB mouse is included to navigate the on-screen menus, and there is a second USB 2.0 port that allows you to save recordings to a USB thumb drive for sharing or viewing on other devices, as well as uploading firmware updates.



CONCORD CDK16282P-V2

Features:
- High Definition Surveillance System
- 8 x Weatherproof 1080p Bullet Cameras (Expandable to 16 cameras)
- 2TB Internal Storage
- PIR Motion Detection
- Smartphone Viewing & Notification

Additional cameras available: Bullet camera QC5220. Dome camera QC5222.

    Specifications

    Digital/Network Video Recorder


    Camera Connection
    BNC
    Video Channels (Direct Connection)
    16ch
    Total Recording Channels
    16ch
    Motion Sensing
    Video Output (Monitor)
    HDMI Type-A, D15 HD (VGA)

    Surveillance Equipment


    Equipment Type
    Surveillance Package (DVR/NVR + Camera)

    Power from Plugpack (secondary)


    DC Plugpack Voltage
    12V
    PSU Powers
    Main Product

    External port details


    External port standard
    10/100Mbps
    External port type
    RJ45

    USB Connectivity


    Supported USB Standards
    USB 2.0
    USB Port Types
    USB Type B

    Video Resolution


    Supported Display Resolution
    1920 x 1080 @ 30fps

    Smartphone App Details


    Apps to suit
    Apple iOS, Android

    CCTV Cameras


    Output Signal
    AHD
    Type of Camera
    Bullet
    Resolution
    1080p (1920 x 1080)

    DVR/Camera Pack


    Cables Included
    8pc
    Cameras Included
    8pc
    Cable Length
    18m

    Internal or Sub-part Dimensions


    Length
    140mm, 300mm
    Dimension details
    Camera, DVR
    Diameter
    70mm

    Product Dimensions


    Length
    140mm, 300mm
    Height
    53mm
    Width
    227mm
    Dimension details
    Camera, DVR

    Product Availability


    Availability
    Stocked item

    Packaged Dimensions


    Packaged Length
    44cm
    Packaged Width
    28cm
    Packaged Weight
    9kg
    Packaged Volume
    35.728l
    Packaged Height
    29cm
    Warranty: 24 Months
