Automotive Fused Relay - SPST 15A
Automotive Fused Relay - SPST 15A
Automotive Fused Relay - SPST 15A

CAT. No. SY4076

Automotive Fused Relay - SPST 15A
product image thumb
product image thumb

Automotive Fused Relay - SPST 15A

$10.95
Designed for automotive applications, these quality relays have an integrated blade fuse and metal mounting bracket. The contacts are rated for 15A, m...
Available

Description

Designed for automotive applications, these quality relays have an integrated blade fuse and metal mounting bracket. The contacts are rated for 15A, making them suitable for installations of aftermarket horns etc.
- 15A fuse included
- QC tab termination

    Specifications

    Relay

    Input
    		 DC
    DC Switching Current (Opening)
    		 15A
    Device Type
    		 Horn Relay
    DC Contact Voltage
    		 12V
    Contact format
    		 SPST

    Power Source Details

    DC Voltage
    		 12V
    DC Current Draw
    		 15A

    Product Dimensions

    Length
    		 33mm
    Height
    		 21mm
    Width
    		 25mm

    Packaged Dimensions

    Packaged Length
    		 3.5cm
    Packaged Width
    		 2.5cm
    Packaged Weight
    		 0.032kg
    Packaged Volume
    		 0.04025l
    Packaged Height
    		 4.6cm

    Product Availability

    Availability
    		 Stocked item

    Downloads

    SY4076-dataSheetMain.pdf
