2 Core Round Screened Audio Cable - Sold per metre
2 Core Round Screened Audio Cable - Sold per metre

CAT. No. WB1504

2 Core Round Screened Audio Cable - Sold per metre
product image thumb

2 Core Round Screened Audio Cable - Sold per metre

$0.98
Light duty round audio signal cable. Includes two conductors for stereo audio signal or similar with a single outer screen. - Single screen for common ground connection - PVC insulation
Available

Description

Light duty round audio signal cable. Includes two conductors for stereo audio signal or similar with a single outer screen. Single screen for common ground connection with grey PVC insulation.

    Specifications

    Packaged Dimensions

    Packaged Length
    		 14.7cm
    Packaged Width
    		 14.9cm
    Packaged Weight
    		 0.01906kg
    Packaged Volume
    		 2.015076l
    Packaged Height
    		 9.2cm

    Wire and Cable

    AWG
    		 28
    Individual Conductor Strand Diameter
    		 0.12mm
    Resistance per Linear Metre
    		 0.2245m?
    Roll Length
    		 100m
    Wire Category
    		 Figure 8 / composite
    Conductor Overall Diameter
    		 0.32mm
    Number of Conductor Strands
    		 7pc
    Retail Sales Unit
    		 Metre
    Cross Sectional Area
    		 0.08mm²

    Product colour

    Colour
    		 Light Grey

    Product Availability

    Availability
    		 Stocked item

    Downloads

    WB1504-dataSheetMain.pdf
