Duinotech 6V Micro Motor with Mounting Brackets

$16.95
Small gearhead motor with bracket suits robotics and other maker applications that runs off 6VDC and has a gear ration of 1:30
Available

Description

This small gearhead motor with bracket suits robotics and other maker applications. It runs from 6VDC, travels counter-clockwise, and provides a 1:30 gear ratio with a rated speed of 600RPM. Micro wheels to suit are available separately (use YG2902).

• Counter-Clockwise Rotation
• 0.5kg Torsion

    Specifications

    Motor

    Motor Type
    		 Gearhead
    Motor Nominal Voltage
    		 6V
    No load RPM
    		 600RPM
    Max. efficiency current
    		 40mA
    Max efficiency RPM
    		 600RPM
    No load current
    		 35mA

    Power Source Details

    DC Current Draw
    		 35mA-40mA
    AC Voltage
    		 5.4V-6.6V

    Gearbox

    Type
    		 Gear Array
    Gear Ratio
    		 1:30
    Pre-assembled Gear

    Internal or Sub-part Dimensions

    Height
    		 12mm, 10mm
    Dimension details
    		 Mount Dimensions, Motor Dimensions
    Width
    		 26mm, 13mm
    Depth
    		 12mm, 37mm

    Product Dimensions

    Height
    		 12mm, 10mm
    Width
    		 26mm, 13mm
    Dimension details
    		 Mount Dimensions, Motor Dimensions
    Depth
    		 12mm, 37mm

    Product Availability

    Availability
    		 Stocked item

    Packaged Dimensions

    Packaged Length
    		 5.1cm
    Packaged Width
    		 6.2cm
    Packaged Weight
    		 0.012kg
    Packaged Volume
    		 0.066402l
    Packaged Height
    		 2.1cm
