Blue 5mm LED 2500mcd Round Clear
Blue 5mm LED 2500mcd Round Clear

CAT. No. ZD0180

Blue 5mm LED 2500mcd Round Clear
product image thumb

Blue 5mm LED 2500mcd Round Clear

$2.95
SpecificationsSize (mm)5ColourBlueLensWaterclearViewing Angle (Degrees)15Wavelength (nm)468IF Typical (mA)20VF Typical (V)3.2IV Typical (mcd)2500IF Ma...
Available

Description

LED

Specifications
Size (mm) 5
Colour Blue
Lens Waterclear
Viewing Angle (Degrees) 15
Wavelength (nm) 468
IF Typical (mA) 20
VF Typical (V) 3.2
IV Typical (mcd) 2500
IF Max Continuous (mA) 30
Preferred Series Resistor (ohms)
5VDC 91
9VDC 300
12VDC 430

    Specifications

    LED Components

    Light Colour
    		 Blue
    Lens Type
    		 waterclear
    Light Wavelength
    		 468nm
    Viewing Angle
    		 15°
    Intensity
    		 2500mcd
    I<sub>f (typ)</sub> - Typical Forward Current
    		 20mA
    Resistor for 12VDC
    		 430?
    V<sub>f (max)</sub> - Maximum Forward Voltage
    		 3.2V
    Resistor for 9VDC
    		 300?
    Illumination Type
    		 Single Colour
    I<sub>f (max)</sub> - Maximum Forward Current
    		 30mA
    LED Type
    		 5mm Standard LED
    Resistor for 5VDC
    		 91?

    Packaged Dimensions

    Packaged Length
    		 4cm
    Packaged Width
    		 0.6cm
    Packaged Weight
    		 0.001kg
    Packaged Volume
    		 0.00144l
    Packaged Height
    		 0.6cm

    Product Availability

    Availability
    		 Stocked item

    Downloads

    ZD0180-dataSheetMain.pdf
