CAT. No. ZZ8552
SMD IC PIC16C711A-20SM - Pack 5
$9.95
From our range of specialty ICs and microcontrollers.
Out of Stock
Description
PIC16C71X Microcontroller Core Features:
• High-performance RISC CPU
• Only 35 single word instructions to learn
• All single cycle instructions except for program branches which are two cycle
• Operating speed: DC - 20 MHz clock input DC - 200 ns instruction cycle
• Up to 2K x 14 words of Program Memory, up to 128 x 8 bytes of Data Memory (RAM)
• Interrupt capability
• Eight level deep hardware stack
• Direct, indirect, and relative addressing modes
• Power-on Reset (POR)
• Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
• Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation
• Programmable code-protection
• Power saving SLEEP mode
• Selectable oscillator options
• Low-power, high-speed CMOS EPROM technology
• Fully static design
• Wide operating voltage range: 2.5V to 6.0V
• High Sink/Source Current 25/25 mA
• Commercial, Industrial and Extended temperature ranges
• Program Memory Parity Error Checking Circuitry with Parity Error Reset (PER) (PIC16C715)
• Low-power consumption: - < 2 mA @ 5V, 4 MHz - 15 µA typical @ 3V, 32 kHz - < 1 µA typical standby current
Data Sheet: http://ww1.microchip.com/downloads/en/DeviceDoc/30272a.pdf
